GE MAC 1600 Service Manual

EquipmentOverview
RearView
RearViewoftheSystem
ItemName
Description
1
Externalpowerconnector12Vpowersupplyforfutureexternaldevices.
Donotuse.
2COMMPortA
Serialconnectorforstressdevices(bicycle
ergometerortreadmill).
3
COMMPortB
Serialconnectorfordatacommunication
withaCASE/CardioSoftorMUSEsystem,or
connectiontoanexternalmodem.
4
PhonejackRJ11connectorfromtheinternalmodemtoan
analogphoneline.
5
ACpowerconnection
StandardconnectorfortheACpowercable.
6USBconnector
StandardUniversalSerialBusconnectorfor
USBdevices,suchastheoptionalbarcode
readerorexternalUSBkeyboard.
7
LANconnection
RJ45networkconnector.
8
SDcardslotSecureDigitalcardslot.Insertthecardas
indicatedbytheicon.Thesystemsupports
onlySDcardsformattedfortheFATorFAT16
lesystems.
2028451-183EMAC™160021

GE MAC 1600 Specifications

General

Brand	GE
Model	MAC 1600
Category	Medical Equipment
Language	English
