EquipmentOverview
RearViewoftheSystem(cont'd.)
ItemName
Description
9
ExternalVideoMonitor
connection
Standard15-pinVGAconnectorforanexternal
monitor.ConnectamedicalgradeVGACRTor
medicalgradeVGAcompatibleLCDdisplay.
NOTE:
Thedisplayresolutionis800by480
pixels.Duetodifferingaspectratios,the
imagemayappeardistortedonsomeLCD
monitors.Consulttheoperatingguidefor
yourLCDmonitor.
10
Equipotentialgrounding
lug
Connectnon-groundedperipheraldevicesto
ensureequipotential.
WARNING:
PATIENTINJURYTotalsystemleakagemustnotexceed300microamperes
(UnitedStates)or500microamperes(international).
Keepleakagecurrentwithinacceptablelimitswhenconnectingauxiliary
equipmenttothisdevice.
Keyboard
NOTE:
TheEnglishkeyboardisshowninthissection.
22MAC™16002028451-183E
