GE MAC 1600 Service Manual

Maintenance
Item
Description
7
patientcable
8
baseplasticassembly
9
middleplasticassembly
10
KISSpump(option)
11
mainboardETEassembly
12
powersupplyassembly
13
printerassembly
14
acquisitionmoduleassembly
PreparingSystemforFRUReplacement
Priortoperforminganydisassemblyprocedures,performthefollowingsteps:
NOTE:
Takestrictprecautionsagainstelectrostaticdischargedamagewhilereplacingeld
replaceableunits.
1.Poweroffthesystem.
2.DisconnectthedevicefromtheACwalloutlet.
3.Disconnectthepowercordfromtherearpanelconnector.
4.Disconnectthepatientcablefromthedeviceasdescribedin“Replacingthe
PatientCable”onpage61.
5.Removethepapertrayassemblyasdescribedin“ReplacingthePaperTray
Assembly”onpage64.
6.Removethebatteryasdescribedin“ReplacingtheBattery”onpage64.
ReplacingthePatientCable
1.DisconnectthesystemfromACpower.
2.Disconnectthepatientcablefromthesidepanelconnectorasshowninthe
followingillustration.
2028451-183EMAC™160061
