GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
3-22 Section 3-5 - Completing the Hardware Installation
Section 3-5
Completing the Hardware Installation
It is recommended to pay attention to the system specifications and make sure the facility has been
prepared in accordance with the information provided in Chapter 2 - Pre-Installation.
For easy reference, the physical specifications of the Vivid™ 3 ultrasound unit are shown in
Table 3-8
below.
When moving the system, always adhere to the following the precautions:
CAUTION: At least two people must be available to deliver and unpack the Vivid™ 3 ultrasound
unit. Attempts to move the unit considerable distances (or on an incline) by one person alone,
could result in personal injury, and/or damage to the system.
CAUTION: The Vivid™ 3 weighs 160 kg (353 lbs) or more - depending on installed peripherals -
when ready for use. Care must be used when moving it or replacing its parts. Failure to follow
the precautions listed could result in injury, uncontrolled motion and costly damage.
ALWAYS:
Be sure the pathway is clear.
Use slow, careful motions.
Use two people when moving the system on inclines or lifting more than 16 kg (35 lbs).
3-5-1 Connecting the Footswitch
1) Connect the triple footswitch to the Footswitch input on the left side of the front panel, as shown in
Figure 3-8 on page 3-11.
2) After connecting the peripherals and switching the system on, configure the footswitch, as
described in System Tab on page 3-36.
Table 3-8 Vivid™ 3 - Physical Specifications
Measurement
Metric
Specifications
Imperial
Specifications
Height (with monitor) 131 — 145 cm 51.6 — 57.1 in
Width 62.5 cm 25 in
Depth
112 cm
(100 cm without rear handle)
44 in
(40 in without rear handle)
Weight 160 kg 353lbs
