GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
3-28 Section 3-5 - Completing the Hardware Installation
3-5-3 Connecting Probes
The Vivid™ 3 ultrasound unit operates with various types of probes that are used for scanning patients,
including flat phased, convex and linear electronic array probes. Once connected, the probes can be
selected for different applications.
Probe connectors on the unit’s control panel are as follows:
• Three active probe connectors (one for a pencil probe), and a fourth, inactive port on the right side
of the unit, which is used for parking.
OR
• Four active probe connectors (one for a pencil probe).
Probes can be connected or changed any time, as described below:
1) Inspect the probe socket to verify that it is free of debris.
2) Hold the rectangular probe connector vertically so that the probe’s cable points upwards.
3) Rotate the probe locking latch counterclockwise to the unlock (horizontal) position.
4) Gently insert the connector into one of the matching sockets on the front of the unit. Gently push
the connector in as far as possible.
5) Rotate the locking latch 90 degrees clockwise to lock the connector into place (vertical).
NOTE: It is not necessary to turn OFF power to connect or disconnect a probe.
3-5-3-1 Available Probes
The following probes are available for use with the Vivid™ 3 ultrasound unit:
Table 3-15 Available Probes
P/N Description
2232337 3S SECTOR (new design)
2259135 7L (546L)
2259145 10L (739L) LINEAR
2259153 C358 PROBE (OUTSIDE JAPAN)
2259206 I739L LINEAR
2295377 12L
2263669 7S SECTOR
2266328 10S
2169773 P509 (Japan)
2259246 T739L LINEAR
KN100011 5T TEE MULTIPLANE
KN100022 6T (Super TEE)
KN100023 8T (Ped TEE)
KN100072 9T(PED TEE) (for RFI systems only)
KZ200476 5S SECTOR
TE100024 Pencil P2D
TQ100002 Pencil P6D
KZ200476 Adaptor PAMPTE/6Tv
2301954 E721
KQ100006 i8L
KW100011 i13L
