Group No. Funcon Color Name Descripon
D3 White/Red NO Lock Wiring
(NO)
D4 Yellow/Green SENSOR Door Contact
D5 Black GND Ground
D6 Yellow/Gray BUTTON Exit Door
Wiring
D7 Yellow/Black GND Ground
4.2 Wire Normal Device
You can connect the terminal with normal peripherals.
Figure 4-1 Device Wiring
Note
• You should set the face
recognion terminal's Wiegand direcon as Input to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand direcon as
Output to transmit authencaon informaon to the access controller.
• For details about Wiegand direcon sengs, see Set Wiegand Parameters .
• The suggested external power supply for door lock is 12 V, 1 A. The suggested external power
supply for the Wiegand card reader is 12 V, 1A.
• Do not wire the device to the electric supply directly.
• If the interface for network
connecon is too large, you can use the supplied cable as shown
below.
DS-K1T341B Series Face Recognion Terminal User Manual
13
