Hirschmann PowerMICE User Manual

Operation Diagnosis
UM Basic Configuration L3P
Release 7.1 12/2011
9.1 Sending Traps
213
9.1.3 Configuring Traps
 Select the Diagnostics:Alarms (Traps) dialog.
This dialog allows you to determine which events trigger an alarm (trap)
and where these alarms should be sent.
 Select “Create”.
 In the "IP Address“ column, enter the IP address of the management
station to which the traps should be sent.
 In the "Enabled“ column, you mark the entries that the device should
take into account when it sends traps. Default setting: inactive.
 In the column "Password", enter the community name that the
device uses to identify itself as the trap's source.
 In the “Configuration” frame, select the trap categories from which
you want to send traps. Default setting: all trap categories are active.
Note: You need read-write access for this dialog.
Figure 50: Alarms dialog
