Operation Diagnosis
UM Basic Configuration L3P
Release
7.1
12/2011
9.11
Reports
239
9.11Reports
The following reports and buttons are available for the diagnostics:
Log file.
The log file is an HTML file in which the device writes all the important
device-internal events.
System information.
The system information is an HTML file containing all system-relevant
data.
Download Switch-Dump.
This button allows you to download system information as files in a ZIP
archive.
In service situations, these reports provide the technician with the necessary
information.
The following button is available as an alternative for operating the Web-
based interface:
Download JAR file.
This button allows you to download the applet of the Web-based interface
as a JAR file. Then you have the option to start the applet outside of a
browser.
This facilitates the device administration even when you have disabled its
web server for security reasons.
Select the Diagnostics:Report dialog.
Click “Log File” to open the HTML file in an own dialog. .
Click “System Information” to open the HTML file in an own dialog.
