Configuring the Ports
UM Basic Configuration L3P
Release
7.1
12/2011
83
Global settings
– For devices with PoE select the
Basic Settings:Power over Ethernet dialog.
– For devices with PoE select the
Basic Settings:Power over Ethernet Plus:Global dialog.
Frame "Operation":
With “Function On/Off” you turn the PoE on or off.
Frame "Configuration":
With “Send Trap” you can get the device to send a trap in the
following cases:
– If a value exceeds/falls below the performance threshold.
– If the PoE supply voltage is switched on/off at at least one port.
Enter the power threshold in “Threshold”. When this value is
exceeded/not achieved, the device will send a trap, provided that
“Send Trap” is enabled. For the power threshold you enter the power
yielded as a percentage of the nominal power.
“Nominal Power” displays the power that the device nominally
provides for all PoE ports together.
“Reserved Power” displays the maximum power that the device
provides to all the connected PoE devices together on the basis of
their classification.
“Delivered Power” shows how large the current power requirement
is at all PoE ports.
The difference between the "nominal" and "reserved" power indicates
how much power is still available to the free PoE+ ports.
