Hirschmann PowerMICE User Manual

Configuring the Ports
UM Basic Configuration L3P
Release 7.1 12/2011
81
5 Configuring the Ports
The port configuration consists of:
 Switching the port on and off
 Selecting the operating mode
 Activating the display of connection error messages
 Configuring Power over ETHERNET.
 Switching the port on and off
In the state on delivery, all the ports are switched on. For a higher level of
access security, switch off the ports at which you are not making any
connection.
 Selecting the operating mode
In the state on delivery, the ports are set to the “Automatic configuration”
operating mode.
Note: The active automatic configuration has priority over the manual
configuration.
 Select the
Basics:Port Configuration dialog.
 In the "Port on" column, select the ports that are connected to
another device.
 Select the
Basics:Port Configuration dialog.
 If the device connected to this port requires a fixed setting
– select the operating mode (transmission rate, duplex mode) in the "Manual
configuration" column and
– deactivate the port in the "Automatic configuration" column.
