Back Accessory Interface Pin-outs
The back accessory interface provides power for peripheral devices out the back of
the 75 Series computers.
Power and Electrical
Rechargeable Li-ion battery pack
(Standard Model)
Model 1001AB01 (PN 318-046-031)
Rechargeable Li-ion battery pack
(Cold Storage Model)
Model 1001AB01 (PN 318-046-032)
Nominal output and capacity 3.7 VDC, 5200 mAh (19.2 Wh)
Environment
Standard Model
Operating temperature -20°C to 60°C (-4°F to 140°F)
Storage temperature -20°C to 60°C (-4°F to 140°F)
Charging temperature 5°C to 35 °C (41°F to 95°F)
Sealant rating IP67
Cold Storage Model
Operating temperature -30°C to 60°C (-22°F to 140°F)
Storage temperature -30°C to 60°C (-22°F to 140°F)
Charging temperature 5°C to 35 °C (41°F to 95°F)
Sealant rating IP65
Relative humidity (operating) 5% to 95% non-condensing
Electrostatic Discharge (ESD) +/-15 kV air discharge, +/-8 kV direct discharge
Screen Specifications
Touch screen • 480 x 640 pixels
• 8.9 cm (3.5 in) Transmissive VGA
• 65,536 (16-bit RGB) colors
• Hardened Corning® Gorilla® Glass display
• LED backlight
• Ambient light sensor
Keypad Options
Keypad Options • Numeric with Function Keys
• Alphanumeric
Parameter Specification
Pin Pin Name I/O Description
1 OTB_PWR Output Power supply for peripheral

Honeywell CK75 Specifications

General

HDD capacity	256 GB
DisplayPorts quantity	3
Audio (L/R) in	0
Composite video out	5.6
DVI-D ports quantity	-
DVI-I ports quantity	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	0.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Display diagonal	3.5 \
Display resolution	480 x 640 pixels
Display number of colors	65536 colors
Flash memory	16 GB
Internal memory	0.002 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	OMAP 4470
Processor frequency	1.5 GHz
Processor manufacturer	Texas Instruments
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Battery capacity	5200 mAh
Operating system installed	Windows Embedded Handheld 6.5
Certification	WEEE, RoHS
Product color	Black
Keyboard layout	Numeric
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Security algorithms	802.1x RADIUS, AES, CCX v4, TKIP, WAPI, WEP, WPA, WPA2
Built-in camera	No
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	50 mm
Width	80 mm
Height	237 mm
Weight	584 g
