Honeywell CK75 User Manual

120 75 Series Mobile Computer User Guide
Imager Specifications
The 75 Series offers these high-performance imager options.
Bar Code Symbologies
2GND
3 OTB_RX Input DTE Data Receive
4 OTB_TX Output DTE Data Transmit
5 OTB_I/O_Voltage Input I/O Voltage Level
6 OTB_ID BiDir One Wire Bus for ID
7 OTB_RTS Output DTE Ready do Send
8 OTB_CTS Input DTE Clear to Send
Pin Pin Name I/O Description
Parameter Specification
Imager
EA30 (CN75/CN75e only) EA30 High-Performance Motion-Tolerant 2D Imager with
(up to 500 in/s) white LED illumination, red laser aimer and
framer optimized for all lighting conditions.
Capable of scanning all common 1D and 2D bar codes,
including 1D as small as 4 mils and 2D as small as 6.6 mils.
EX25 (CK75 only) Near/Far High-Performance 2D Imager
Capable of scanning 1D and 2D bar codes from 15.2 cm to
16.2 m (6 in to 50 ft).
N5603ER (CK75 only) High-Performance 2D Imager:
Capable of scanning all common 1D and 2D bar codes,
including 1D as small as 5 mil and standard UPC codes up to
53 cm (21 in).
Supported Bar Code Symbologies
AustraliaPost DataMatrix Maxicode
Aztec Dutch Post Micro PDF417
BPO EAN/UPC MSI
Canada Post GS1 Composite PDF417
China Post GS1 DataBar Expanded Planet
Codabar GS1 DataBar Limited Plessey
Codablock A HanXin Postnet
Codablock F Infomail QR Code
Code 11 Interleaved 2 of 5 Standard 2 of 5
Code 39 Japan Post SwedenPost
Code 93 KoreanPost Telepen

Honeywell CK75 Specifications

General

HDD capacity	256 GB
DisplayPorts quantity	3
Audio (L/R) in	0
Composite video out	5.6
DVI-D ports quantity	-
DVI-I ports quantity	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	0.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Display diagonal	3.5 \
Display resolution	480 x 640 pixels
Display number of colors	65536 colors
Flash memory	16 GB
Internal memory	0.002 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	OMAP 4470
Processor frequency	1.5 GHz
Processor manufacturer	Texas Instruments
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Battery capacity	5200 mAh
Operating system installed	Windows Embedded Handheld 6.5
Certification	WEEE, RoHS
Product color	Black
Keyboard layout	Numeric
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Security algorithms	802.1x RADIUS, AES, CCX v4, TKIP, WAPI, WEP, WPA, WPA2
Built-in camera	No
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	50 mm
Width	80 mm
Height	237 mm
Weight	584 g
