Honeywell CK75 User Manual

22 75 Series Mobile Computer User Guide
About the CK75 Cold Storage Model Heater
CK75 Cold Storage (CS) models come equipped with touch screen and scan
window heaters to support extended use in freezers as well as transitions into and
out of freezer areas.
CK75 cold storage models have external Temperature Monitoring enabled by
default to determine when the computer enters a cold storage environment. Once
the ambient temperature drops below the Heater Enable Temperature, the system
starts a Heater enabled delay timer.
Once the Heater enabled delay timer expires, the system operates in one of two
configurable modes:
• Automatic mode for maximizing battery life in cold storage environments and
average window defrost times. In freezer heater activation is disabled.
• Preemptive mode (Pre-heat) for minimizing window defrost times with average
battery life in cold storage environments. In freezer heater activation is enabled.
How Automatic Mode Works
Automatic mode maximizes the cold storage battery life by only turning the heater
on once the following conditions are met in the order listed:
1. The computer detects the ambient temperature has lowered below the set
Heater enable temperature.
2. The Heater enabled delay timer expires. A snowflake icon appears in the
status bar.
3. The computer detects a quick rise in the ambient temperature indicating an exit
from cold storage.
If you remove the computer from cold storage before the Heater enabled delay
timer expires, the system does not turn on the heater, saving battery power.
Note: When the heaters turn on in Automatic Mode, the icon changes from a
snowflake to a heater .
In Automatic mode, cold storage battery life may exceed 6 hours (scanning a bar
code every ten seconds). Window defrost times should be a minute or less with
factory default settings implemented.
You can configure the heater operation for your individual environment in
Enterprise Settings or by editing the computer registry values. To learn more, see
Configure the Heater Feature on page 24.

Honeywell CK75 Specifications

General

HDD capacity	256 GB
DisplayPorts quantity	3
Audio (L/R) in	0
Composite video out	5.6
DVI-D ports quantity	-
DVI-I ports quantity	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	0.7
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Display diagonal	3.5 \
Display resolution	480 x 640 pixels
Display number of colors	65536 colors
Flash memory	16 GB
Internal memory	0.002 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	OMAP 4470
Processor frequency	1.5 GHz
Processor manufacturer	Texas Instruments
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Battery capacity	5200 mAh
Operating system installed	Windows Embedded Handheld 6.5
Certification	WEEE, RoHS
Product color	Black
Keyboard layout	Numeric
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Security algorithms	802.1x RADIUS, AES, CCX v4, TKIP, WAPI, WEP, WPA, WPA2
Built-in camera	No
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	50 mm
Width	80 mm
Height	237 mm
Weight	584 g

Summary

About the Computer Features

About the 75 Series Mobile Computers

Introduces the 75 Series Mobile Computers, their operating system, and general characteristics.

About the Battery

Details the rechargeable Lithium-ion battery packs used by the computers and their specifications.

About the Keypad

Use the Phone

About the Phone

Details the phone features, speaker, microphone, and Bluetooth headset support.

How to Add and Switch Between Network Carriers

Explains how to add carriers and switch between WWAN networks.

Activate the UMTS Phone

Provides steps to activate the UMTS phone using a SIM card.

Activate the CDMA Phone

Guides on activating the CDMA radio module with a wireless carrier.

Use the Camera

About the Color Camera

How to Take Pictures and Record Videos

Explains using the Pictures & Videos application for capturing media.

How to Read Bar Codes with the Camera

Configure the Computer

How to Configure the Computer

Details methods for configuring parameters like symbologies and network settings.

About Enterprise Settings on the Computer

Explains how to use Enterprise Settings to configure Honeywell applications.

Configure the Computer Remotely with SmartSystems

Configure 802.11 Radio Communications

About Bluetooth Communications

How to Make Your Security Choice

Discusses security options like Funk, Microsoft, and Reliable Access Client (RAC).

Manage the Computer

How to Manage the Computer in Your Network

Essential ways to manage updates, configure devices, and troubleshoot remotely.

Manage the Computer Using SmartSystems

Utilizes SmartSystems software platform for managing devices from a central server.

How to Develop and Install Applications

How to Update the System Software

Describes methods for updating the operating system and system software.

Troubleshoot and Maintain the Computer

About the Dashboard

Explains the dashboard for proactive monitoring and troubleshooting device issues.

About Troubleshoot the Computer

Provides troubleshooting sections for common problems and device operation.

Wi-Fi Connection Problems

802.1x Security Problems

Troubleshoot the Scanner with Scan Diagnostic

Problems Reading Bar Codes

How to Restart the Computer

Specifications

Physical and Environmental Specifications

Lists the physical dimensions, weight, and environmental operating conditions.

CN75/CN75e

CK75

Imager Specifications
