375
To do... Use the command... Remarks
Display the information of
join/prune messages to send
display pim ipv6 join-prune mode { sm [ flags flag-
value ] | ssm } [ interface interface-type interface-
number | neighbor ipv6-neighbor-address ] * [
verbose ] [ | { begin | exclude | include } regular-
expression ]
Available in
any view
Display IPv6 PIM neighboring
information
display pim ipv6 neighbor [ interface interface-type
interface-number | ipv6-neighbor-address | verbose
] * [ | { begin | exclude | include } regular-
expression ]
Available in
any view
Display the content of the IPv6
PIM routing table
display pim ipv6 routing-table [ ipv6-group-address [
prefix-length ] | ipv6-source-address [ prefix-length ]
| incoming-interface [ interface-type interface-
number | register ] | outgoing-interface { include |
exclude | match } { interface-type interface-number |
register } | mode mode-type | flags flag-value | fsm
] * [ | { begin | exclude | include } regular-
expression ]
Available in
any view
Display the RP information
display pim ipv6 rp-info [ ipv6-group-address ] [ | {
begin | exclude | include } regular-expression ]
Available in
any view
Reset IPv6 PIM control message
counters
reset pim ipv6 control-message counters [ interface
interface-type interface-number ]
Available in
user view
IPv6 PIM configuration examples
IPv6 PIM-DM configuration example
Network requirements
• Receivers receive VOD information through multicast. The receiver groups of different organizations
form stub networks, and one or more receiver hosts exist in each stub network. The entire IPv6 PIM
domain operates in the dense mode.
• Host A and Host C are multicast receivers in the stub networks N1 and N2.
• Switch D connects to the network that comprises the multicast source—Source—through VLAN-
interface 300.
• Switch A connects to N1 through VLAN-interface 100 and to Switch D through VLAN-interface
103.
• Switch B and Switch C connect to N2 through their respective VLAN-interface 200 and to Switch D
through VLAN-interface 101 and VLAN-interface 102, respectively.
• MLDv1 will run between Switch A and N1 and between Switch B/Switch C and N2.
