HP b2600 Technical Reference

Chapter 5 133
Block Diagram
System Board and PCI Board
PCI Back-Plane Board
The B2600 includes four I/0 expansion slots that allow functionality beyond the core I/O
functions. The four I/O slots are all PCI slots. Two of the slots are 5V, 32-bit, 33MHz, PCI
1x capable slots. The other two slots are 5V, 64-bit, 33MHz, PCI 2x capable slots. The two
32-bit slots will support half-length PCI cards. The two 64-bit slots will support full-length
PCI cards. The physical configuration for the add-in slots in the B2600 is shown in Figure
5-2.
Figure 5-2. PCI Slots for the B2600 Workstation
Rear of
Workstation
Slot 1 PCI 1x
Slot 2 PCI 1x
Slot 3 PCI 2x
Slot 4 PCI 2x
1/2 length cards only
1/2 length cards only
5V, 32 bit, 33MHz
5V, 32 bit, 33MHz
5V, 64 bit, 33MHz
5V, 64 bit, 33MHz
