HP b2600 Technical Reference

40 Chapter3
Remove/Replace System Components
Removing/Replacing System Components
Removing the Front Bezel and Top Cover
This section describes how to remove the HP B2600 workstation’s front bezel and top
cover. Once you have removed these system components, you will have access to the
interior components of your system.
Removing the Front Bezel and Top Cover
1. Turn your workstation off and unplug it.
2. Lay your workstation on a soft anti-static surface with the HP logo text in the upright
position.
3. Press in on both release buttons found on the ends of the bezel and pull outward from
the workstation to remove it. Next, unscrew the captive screws and pull forward on the
cover and lift it off. See Figure 3-1.
Figure 3-1. Front Bezel and Top Cover Removal
Bezel Release Buttons Captive Screws
