Your Workstation’s Rear Panel Connectors
Your Workstation’s Rear Panel Connectors
This section describes the following connectors on the system unit’s rear panel:
• Serial Ports 1 and 2 Connectors
• USB Connectors
• Power Cord Connector
• Parallel Connector
• Network Connector
NOTE To maintain FCC/EMI compliance, verify that all cables are fully seated and
properly fastened.
Figure 1-3.
shows the locations of the connectors on the system unit’s rear panel.
Figure 1-3. System Unit Rear Panel Connectors
Serial
Port 1
Serial
Port 2
USB Connectors
Power Cord
Connector
Parallel Connector
10/100 Base T Connector
I/O Card Slots
To Next Page
