Item Description
Installation
space
The server fits into a universal cabinet that complies with the IEC 297
standard.
l Cabinet width: 19 in.
l Cabinet depth: ≥ 1000 mm (39.37 in.)
Requirements for guide rail installation:
l L-shaped guide rails: apply only to a Huawei cabinet.
l Adjustable guide rails: apply to a cabinet with a distance of 543.5 mm
to 848.5 mm (21.40 in. to 33.41 in.) between the front and rear
mounting bars.
l Holding rails: apply to a cabinet with a distance of 610 mm to 914
mm (24.02 in. to 35.98 in.) between the front and rear mounting bars.
Weight in full
configuration
Net weight:
l With eight 2.5-inch front drives and four 2.5-inch rear drives: 25.1 kg
(55.35 lb)
l With twelve 3.5-inch front drives, four 3.5-inch rear drives, and four
2.5-inch rear drives: 34.1 kg (75.19 lb)
l With twenty-four 2.5-inch front drives and four 2.5-inch rear drives:
29.4 kg (64.83 lb)
l With twenty-five 2.5-inch front drives, two 3.5-inch rear drives, and
four 2.5-inch rear drives: 30.5 kg (67.25 lb)
Packaging materials: 5 kg (11.03 lb)
Power
consumption
The power consumption varies with the server configuration. Use the
Huawei Server Power Calculator to calculate the power consumption.
Acoustic noise The data listed in the following is the declared A-weighted sound power
levels (LWAd) and declared average bystander position A-weighted
sound pressure levels (LpAm) when the server is operating in a 23°C
(73.4°F) ambient environment. Noise emissions are measured in
accordance with ISO 7779 (ECMA 74) and declared in accordance with
ISO 9296 (ECMA 109).
l Idle:
– LWAd: 5.64 Bels
– LpAm: 42.2 dBA
l Operating:
– LWAd: 6.08 Bels
– LpAm: 46.8 dBA
NOTE
The actual sound levels generated when the server is operating vary depending on
the server configuration, workload, and ambient temperature.
Environmental Specifications
l Temperature
2288H V5 Server
User Guide
13 Product Specifications
Issue 04 (2018-09-04) Copyright © Huawei Technologies Co., Ltd. 252
