Huawei 2288H V5 User Manual

Configurati
on
Maximum
Front Drives
Maximum Rear Drives Maximu
m Built-
in
Drives
SATA/S
AS
DriveMa
nagemen
t Mode
Server with
twelve 2.5-
inch NVMe
SSDs
20
1. Slots 0 to 7:
8 (SAS/
SATA
drive)
[6]
2. Slots 8 to
19: 12
(NVMe
SSD)
I/O module 3: 4 (NVMe SSD) - One
RAID
controller
card/PCH
Server with
twenty-four
2.5-inch
drives (pass-
through)
[1]
24 (SATA or
SAS drive)
I/O module 3: 4 (NVMe SSD) - Three
RAID
controller
cards (one
for eight
drives)
Server with
twenty-four
2.5-inch
NVMe
SSDs
[1]
24
1. Slots 0 to 3:
4 (SAS/
SATA drive
or NVMe
SSD)
2. Slots 4 to
23: 20
(NVMe
SSD)
I/O module 3: 4 (NVMe SSD) - One
RAID
controller
card
Server with
twenty-five
2.5-inch
drives
(expander)
1
[1]
25 (SATA or
SAS drive)
l I/O module 1: 2 (SATA or
SAS drive)
l I/O module 3: 4 (SAS/SATA
drive or NVMe SSD)
[2]
- One
RAID
controller
card
Server with
twenty-five
2.5-inch
drives
(expander)
2
[1]
25 (SATA or
SAS drive)
l I/O module 1: 2 (SATA or
SAS drive)
l I/O module 3: 4 (NVMe
SSD)
- Two
RAID
controller
cards
2288H V5 Server
User Guide
2 Components
Issue 04 (2018-09-04) Copyright © Huawei Technologies Co., Ltd. 29

Huawei 2288H V5 Specifications

General

Form Factor	2U rack server
Processor	Intel Xeon Scalable processors
Max Processors	2
Memory	24 DDR4 DIMM slots
Storage	Supports 25 x 2.5-inch drives
RAID Support	RAID levels 0, 1, 5, 6, 10, 50, 60
Network	2 x GE ports
Expansion Slots	Multiple PCIe slots
Power Supply	800W/1200W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
