admin:/>add white_list sn=XXXXXXXXXXXXXXXXXXXX
Command executed successfully.
3. (Optional) Run the change white_list enable_switch=no command to close the whitelist
if you do not need to configure it.
----End
4.4.3 Configuring the Arbitration Software (Ubuntu)
This section describes how to configure the arbitration software in Ubuntu.
Prerequisites
The arbitration software must be configured in user mode.
Procedure
Step 1 Prepare for the configuration.
Before the configuration, make sure that the quorum server has been configured with service
IP address and firewall.
1. Configure a service IP address for the quorum server.
NOTE
If two ports of the quorum server are not bonded, IP addresses of the two ports must be from different
network segments. If the two ports of the quorum server are bonded, you only need to configure a
virtual IP address for arbitration.
– When deploying the arbitration software using VMs, you need to create virtual
network adapters and switches for VMs. In this example, arbitration software is
deployed on VMs, and two ports of the quorum server are not bonded. Figure 4-4
and Table 4-6 show configuration requirements.
Figure 4-4 Configuration requirements of virtual network adapters
OceanStor V3 Series
HyperMetro Feature Guide for File
4 Configuration
Issue 05 (2018-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
76
