IS620P User Manual Chapter 7 Function Code Table
- 165 -
Group H03: Input Terminal Parameters
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H03 00
Function
allocation 1 of
DIs that are
set to ON and
effective
0–0xFFFF
Bit0: FunIN.1
Bit1: FunIN.2
……
Bit15: FunIN.16
- 0
Power-on
again
During
running
-
H03 01
Function
allocation 2 of
DIs that are
set to ON and
effective
0–0xFFFF
Bit0: FunIN.17
Bit1: FunIN.18
……
Bit15: FunIN.32
- 0
Power-on
again
During
running
-
H03 02
DI1 function
selection
0–37 - 14 Upon stop
During
running
-
H03 03
DI1 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 04
DI2 function
selection
0–37 - 15 Upon stop
During
running
-
H03 05
DI2 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 06
DI3 function
selection
0–37 - 13 Upon stop
During
running
-
H03 07
DI3 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 08
DI4 function
selection
0–37 - 2 Upon stop
During
running
-

Inovance IS620PT012I Specifications

General

Series	IS620P
Rated Output Current	12A
Control Mode	Position, Speed, Torque
Communication Interface	RS485, CANopen
Protection Level	IP20
Rated Current	12A
Output Current	12A
Feedback	Incremental Encoder
