6. Description of Parameters
- 102 -
Function Code Parameter Name Setting Range Default
FC-41
Acceleration/deceleration time of
simple PLC reference 11
0 to 3 0
FC-42
Running time of simple PLC
reference 12
0.0s (h) to 6553.5s (h) 0.0s (h)
FC-43
Acceleration/deceleration time of
simple PLC reference 12
0 to 3 0
FC-44
Running time of simple PLC
reference 13
0.0s (h) to 6553.5s (h) 0.0s (h)
FC-45
Acceleration/deceleration time of
simple PLC reference 13
0 to 3 0
FC-46
Running time of simple PLC
reference 14
0.0s (h) to 6553.5s (h) 0.0s (h)
FC-47
Acceleration/deceleration time of
simple PLC reference 14
0 to 3 0
FC-48
Running time of simple PLC
reference 15
0.0s (h) to 6553.5s (h) 0.0s (h)
FC-49
Acceleration/deceleration time of
simple PLC reference 15
0 to 3 0
FC-16 determines the simple PLC running mode.
Function Code Parameter Name Setting Range Default
FC-16
Simple PLC
running mode
0: Stop after running one cycle
1: Keep nal values after running one cycle
2: Repeat after running one cycle
0
● FC-16 = 0: Stop after running one cycle
The AC drive stops after running one cycle, and will not start until it receives a new
RUN command.
● FC-16 = 1: Keep nal values after running one cycle
The AC drive keeps nal running frequency and direction after running one cycle.
● FC-16 = 2: Repeat after running one cycle
The AC drive automatically starts another cycle after running one cycle, and will not
stop until receiving stop command.
FC-17 determines whether the running data is retentive at power down or at stop.
If retentive, the running data is memorized at power down or at stop and the AC drive will
continue to run from the memorized data at next power-on.
If not retentive, the AC drive runs from the rst simple PLC reference at next power-on.
Function Code Parameter Name Setting Range Default
FC-17
Simple PLC retentive
selection
0: Not retentive
1: Retentive
00
Unit position: Retentive at power down
Tens position: Retentive at stop
