Related function parameters are as follows:
Function Code Parameter Name Setting Range Default
Fb-00
Wobble setting mode 0: Relative to the frequency reference
1: Relative to the max. frequency
0
This function parameter selects base value of wobble amplitude.
Function Code Parameter Name Setting Range Default
Fb-01
Wobble amplitude 0.0% to 100.0% 0.0%
Fb-02
Wobble step 0.0% to 50.0% 0.0%
Fb-01 and Fb-02: These function parameters set wobble amplitude and wobble step.
● When Fb-00 = 0, Aw (wobble amplitude) = F0-07 (Frequency source superposition selection)
x Fb-01.
● When Fb-00 = 1, Aw (wobble amplitude) = F0-10 (Max. frequency) x Fb-01.
Wobble step frequency = Aw (wobble amplitude) x Fb-02 (Wobble step). The wobble running
frequency must be within frequency upper limit and frequency lower limit.
Function Code Parameter Name Setting Range Default
Fb-03
Wobble cycle 0.0s to 3000.0s 10.0s
Fb-04
Triangular wave rising
time coefcient
0.0% to 100.0% 50.0%
Fb-03: It species time of a complete wobble cycle.
Fb-04: It is percentage of triangular wave rising time to Fb-03 (Wobble cycle).
● Triangular wave rising time = Fb-03 (Wobble cycle) x FB-04 (Triangular wave rising time
coefcient, unit: s)
● Triangular wave falling time = Fb-03 (Wobble cycle) x (1 - Fb-04 Triangular wave rising time
coefcient, unit: s)
6.8.2 Fixed Length Control
The drive has the xed length control function. The length pulses can only be sampled by DI5.
Set DI5 for function 27 "Length signal pulses count".
Function Code Parameter Name Setting Range Default
Fb-05
Set length 0 to 65535 m 1000 m
Fb-06
Actual length 0 to 65535 m 0 m
Fb-07
Number of pulses per
meter
0.1 to 6553.5 100.0
In the following gure, actual length is a monitored value.
Actual length (Fb-06) = Number of pulses sampled by DI is divided by Fb-07 (Number of pulses
each meter).
When actual length reaches the value set in Fb-05, digital output terminal set for function 10
“Length reached” becomes on. Length reset can be implemented via DI terminal set for function
28 "Length reset".
