Inovance MD500 Series User Manual

Appendix. Parameter Table
- 310 -
12
Parameter
No.
Parameter Name Setting Range Default Property Page
F0-22 Frequency reference resolution 2 2
★
-
F0-23 Retentive of digital setting
frequency upon stop
0, 1 0
☆
9
2
F0-24 Motor parameter group selection 0, 1 0
★
1
5
8
F0-25 Acceleration/Deceleration time
base frequency
0 to 2 0
★
1
2
3
F0-26 Base frequency for UP/DOWN
modication during running
0, 1 0
★
-
F0-27 Command source + frequency
source
000 to 999 000
☆
1
1
5
F0-28 Serial port comms. protocol 0, 1 0
★
8
9
Group F1: Motor 1 Parameters
F1-00 Motor type selection 0, 1 0
★
1
2
6
F1-01 Rated motor power 0.1 to 1000.0 kW Model
dependent
★
1
2
6
F1-02 Rated motor voltage 1 to 2000 V Model
dependent
★
1
2
6
F1-03 Rated motor current 0.01 to 655.35 A (AC drive
power ≤ 55 kW)
0.1 to 6553.5 A (AC drive
power > 55 kW)
Model
dependent
★
1
2
6
F1-04 Rated motor frequency 0.01 Hz to max. frequency Model
dependent
★
1
2
6
F1-05 Rated motor speed 1 to 65535 rpm Model
dependent
★
1
2
6
F1-06 Stator resistance 0.001 to 65.535 Ω (AC drive
power ≤ 55 kW)
0.0001 to 6.5535 Ω (AC
drive power > 55 kW)
Auto-tuning
dependent
★
1
2
6
F1-07 Rotor resistance 0.001 to 65.535 Ω (AC drive
power ≤ 55 kW)
0.0001 to 6.5535 Ω (AC
drive power > 55 kW)
Auto-tuning
dependent
★
1
2
6
F1-08 Leakage inductive reactance 0.01 to 655.35 mH (AC
drive power ≤ 55 kW)
0.001 to 65.535 mH (AC
drive power > 55 kW)
Auto-tuning
dependent
★
1
2
6
F1-09 Mutual inductive reactance 0.1 to 6553.5 mH (AC drive
power ≤ 55 kW)
0.01 to 655.35 mH (AC
drive power > 55 kW)
Auto-tuning
dependent
★
1
2
6
F1-10 No-load current 0.01 A to F1-03 (AC drive
power ≤ 55 kW)
0.1 A to F1-03 (AC drive
power > 55 kW)
Auto-tuning
dependent
★
1
2
6
F1-27 Encoder pulses per revolution 1 to 65535 1024
★
1
2
7
F1-28 Encoder type 0: ABZ incremental encoder
2: Resolver
0
★
1
2
7
