Goodrive300 Series VFD Quick start-up

Chapter 2 Quick start-up

2.1 What this chapter contains

This chapter mainly describes the basic guidelines for the installation and commission procedures on

the VFD, which you may follow to install and commission the VFD quickly.

2.2 Unpacking inspection

Check as follows after receiving products:

1. Check whether the packing box is damaged or dampened. If yes, contact local dealers or

company offices.

2. Check the model identifier on the exterior surface of the packing box is consistent with the

purchased model. If no, contact local dealers or company offices.

3. Check whether the interior surface of packing box is abnormal, for example, in wet condition,

or whether the enclosure of the VFD is damaged or cracked. If yes, contact local dealers or

company offices.

4. Check whether the name plate of the VFD is consistent with the model identifier on the

exterior surface of the packing box. If no, contact local dealers or company offices.

5. Check whether the accessories (including the user manual, control keypad and extension

card) inside the packing box are complete. If no, contact local dealers or company offices.

2.3 Application confirmation

Check the machine before beginning to use the VFD:

1. Check the load type to verify that there is no overload of the VFD during work and check that

whether the drive needs to modify the power degree.

2. Check that the actual current of the motor is less than the rated current of the VFD.

3. Check that the control accuracy of the load is the same of the VFD.

4. Check that the incoming supply voltage is correspondent to the rated voltage of the VFD.

5. Check that the communication needs option card or not.

2.4 Environment

Check as followings before the actual installation and usage:

1. Check that the ambient temperature of the VFD is below 40°C . If temperature is above 40°C,

derate 1% for every additional 1°C . Additionally, the VFD cannot be used if the ambient

temperature is above 50°C .

Note: for the cabinet VFD, the ambient temperature means the air temperature inside the

cabinet.

2. Check that the ambient temperature of the VFD in actual usage is above -10°C . If not, add

heating facilities.

Note: for the cabinet VFD, the ambient temperature means the air temperature inside the

cabinet.
