Goodrive300 Series VFD Product overview
11
Built-in for VFDs of 380V (≤30kW), optional for VFDs
of 380V (≥37kW)
Built-in for VFDs of 500V (≤18.5kW), optional for VFDs
of 500V (≥22kW)
Optional for VFDs of 660V
The whole series of 380V VFDs can meet the
requirements of level C3 stipulated in IEC61800-3.
External filters that meet the requirements of level C2
stipulated in IEC61800-3 are optional.
3.4 Name plate
Figure 3-6 Name plate
Note: The CE/TUV/IP20 marking is displayed on the top right only when the corresponding
CE/TUV/IP20 certification is obtained.
3.5 Model code
The model code contains information about the VFD. You can find the model code on the name plate
on the VFD or the simplified name plate.
Figure 3-7 Product type
GD300 is short for Goodrive300.
5R5—5.5kW
G—Constant torque load
4: AC 3PH 380V (-15%)–440V (+10%)
