INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
141
Function
code
Name
Detailed instruction of parameters
Default
value
9: Reserved
P03.16
Keypad setting for
upper frequency of
forward rotation in
torque control
0.00Hz–P00.03 (Max. frequency)
50.00 Hz
P03.17
Keypad setting for
upper frequency of
reverse rotation in
torque control
0.00 Hz–P00.03 (Max. frequency)
50.00 Hz
P03.18
Upper
electromotion
torque limit setting
source
0: Keypad setting upper-limit frequency (P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
4: HDI
5: Modbus communication
6: PROFIBUS/CANopen communication
7: Ethernet communication
8: Reserved
0
P03.19
Upper braking
torque limit setting
source
0
P03.20
Keypad setting of
upper
electromotion
torque limit
0.0–300.0% (rated current of the motor)
180.0%
P03.21
Keypad setting of
upper braking
torque limit
0.0–300.0% (rated current of the motor)
180.0%
P17.09
Output torque
-250.0–250.0%
0.0%
P17.15
Torque reference
-300.0–300.0% (rated current of the motor)
0.0%
7.6 Parmeters of the motor
• Physical accident may occur if the motor starts up suddenly during autotune.
Please check the safety of surrounding environment of the motor and the load
before autotune.
• The power is still applied even the motor stops running during static autotune.
Please do not touch the motor until the autotune is completed, otherwise there
would be electric shock.
