INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
175
Function
code
Name
Detailed instruction of parameters
Default
value
P10.23
Running time of step 10
0.0–6553.5s (min)
0.0s
P10.24
Multi-step speed 11
-100.0–100.0%
0.0%
P10.25
Running time of step 11
0.0–6553.5s (min)
0.0s
P10.26
Multi-step speed 12
-100.0–100.0%
0.0%
P10.27
Running time of step 12
0.0–6553.5s (min)
0.0s
P10.28
Multi-step speed 13
-100.0–100.0%
0.0%
P10.29
Running time of step 13
0.0–6553.5s (min)
0.0s
P10.30
Multi-step speed 14
-100.0–100.0%
0.0%
P10.31
Running time of step 14
0.0–6553.5s (min)
0.0s
P10.32
Multi-step speed 15
-100.0–100.0%
0.0%
P10.33
Running time of step 15
0.0–6553.5s (min)
0.0s
P10.36
PLC restart
0: Restart from the first stage
1:Continue to run from the stop
frequency
0
P10.34
Simple PLC 0–7 step
ACC/DEC time
0x0000–0XFFFF
0000
P10.35
Simple PLC 8–15 step
ACC/DEC time
0x0000–0XFFFF
0000
P05.01–
P05.09
Digital input function
selection
23:Simple PLC stop reset
24:Simple PLC pause
P06.01–
P06.04
Digital outnput function
selection
15: Underload pre-alarm
16:Completion of simple PLC stage
P17.00
Setting frequency
0.00Hz–P00.03
(Max. output frequency)
0.00Hz
P17.27
Simple PLC and the
current stage of the
multi-step speed
0–15
7.14 Multi-step speed running
Set the parameters when the VFD carries out multi-step speed running. Goodrive300 series VFDs
can set 16 stage speed which can be selected by the combination code of multi-step speed terminals
1–4. They correspond to multi-step speed 0 to 15.
