Goodrive300 Series VFD Basic operation instruction
158
Function
code
Name
Detailed instruction of parameters
Default
value
P05.44
Middle value of AI3
P05.42P05.46
0.00V
P05.45
Corresponding middle
setting of AI3
-100.0%100.0%
0.0%
P05.46
Upper limit of AI3
P05.4410.00V
10.00V
P05.47
Corresponding setting of
the upper limit of AI3
-100.0%100.0%
100.0%
P05.48
AI3 input filter time
0.000s10.000s
0.100s
P05.49
HDI high-speed pulse
input function
selection
0: Frequency setting input, frequency
setting source
1: Counter input, high-speed pulse
counter input terminals
2: Length counting input, length counter
input terminals
0
P05.50
Lower limit frequency of
HDI
0.000kHzP05.52
0.000kHz
P05.51
Corresponding setting of
HDI low frequency setting
-100.0%100.0%
0.0%
P05.52
Upper limit frequency of
HDI
P05.5050.000kHz
50.000
kHz
P05.53
Corresponding setting of
upper limit frequency of
HDI
-100.0%100.0%
100.0%
P05.54
HDI frequency input filter
time
0.000s10.000s
0.100s
7.10 Analog output
Goodrive300 series VFDs have 2 analog output terminals (010V or 020mA) and 1 high speed
pulse output terminal. Analog output signal can be filtered and the maximum and minimum values can
be adjusted. The analog output signals can be proportional to motor speed, output frequency, output
current, motor torque, motor power, etc.
