Goodrive300 Series VFD Basic operation instruction
138
Function
code
Name
Description
Default
value
P04.20
V/F
frequency 3 of motor 2
P04.18– P02.02 or P04.18– P02.16
0.00Hz
P04.21
V/F
voltage 3 of motor 2
0.0%–110.0%
0.0%
P04.22
V/F slip compensation
gain of motor 2
0.0–200.0%
100.0%
P04.23
Vibration control factor at
low frequency of motor 2
0–100
10
P04.24
Vibration control factor at
high frequency of motor 2
0–100
10
P04.25
Vibration control threshold
of motor 2
0.00Hz–P00.03 (Max. frequency)
30.00 Hz
P04.26
Energy-saving operation
0: No action
1: Automatic energy-saving running
0
P04.27
Voltage setting
0: Keypad: the output voltage is
determined by P04.28.
1: AI1
2: AI2
3: AI3
4: HDI
5: Multi-step speed
6: PID;
7: Modbus communication;
8: PROFIBUS/CANopen communication;
9: Ethernet communication (reserved)
10: Reserved
0
P04.28
Keypad setting voltage
0.0%–100.0%
(rated voltage of the motor)
100.0%
P04.29
Voltage increasing time
0.0–3600.0s
5.0s
P04.30
Voltage decreasing time
0.0–3600.0s
5.0s
P04.31
Max. output voltage
P04.32–100.0%
(rated voltage of the motor)
100.0%
P04.32
Min. output voltage
0.0%–P04.31 (rated voltage of the motor)
0.0%
7.5 Torque control
Goodrive300 series VFDs support two kinds of control mode: torque control and rotation speed
control. The core of rotation speed is that the whole control focuses on the stable speed and ensures
the setting speed is the same as the actual running speed. The Max. Load sould be in the range of
