INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Product overview
14
Model
Rated output power
(kW)
Rated input current
(A)
Rated output
current (A)
GD300-055G-6
55
65
62
GD300-075G-6
75
85
86
GD300-090G-6
90
95
98
GD300-110G-6
110
118
120
GD300-132G-6
132
145
150
GD300-160G-6
160
165
175
GD300-185G-6
185
190
200
GD300-200G-6
200
210
220
GD300-220G-6
220
230
240
GD300-250G-6
250
255
270
GD300-280G-6
280
286
300
GD300-315G-6
315
334
350
GD300-350G-6
350
360
380
GD300-400G-6
400
411
430
GD300-500G-6
500
518
540
GD300-560G-6
560
578
600
GD300-630G-6
630
655
680
Note:
1. The input current of VFDs 22–350kW is detected when the input voltage is 660V and there are no
DC reactors and input/output reactors.
2. The input current of VFDs 400–630kW is detected when the input voltage is 660V and there are
input reactors.
3. The rated output current is defined as the output current generated when the output voltage is
660V.
4. Within the allowed input voltage range, the output current cannot exceed the rated output current,
and the output power cannot exceed the rated output power.
3.7 Structure diagram
Figure 3-8 shows the layout of the VFD (taking the VFD of 380V 30kW as an example).
