INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Fault tracking
189
Chapter 8 Fault tracking
8.1 What this chapter contains
This chapter describes how to reset faults and view fault history. It also lists all alarm and fault
messages including the possible cause and corrective actions.
• Only qualified electricians are allowed to maintain the VFD. Read the safety
instructions in Chapter 1 "Safety precautions" before working on the VFD.
8.2 Alarm and fault indications
Fault is indicated by LEDs. See Chapter 5 "Keypad operation procedure". When TRIP light is on, an
alarm or fault message on the panel display indicates abnormal VFD state. Using the information
given in this chapter, most alarm and fault cause can be identified and corrected. If not, contact with
the INVT office.
8.3 How to reset
The VFD can be reset by pressing the keypad key STOP/RST, through digital input, or by switching
the power light. When the fault has been removed, the motor can be restarted.
8.4 Fault history
Function codes P07.27–P07.32 store 6 recent faults. Function codes P07.33–P07.40, P07.41–P7.48,
P07.49–P07.56 show drive operation data at the time the latest 3 faults occurred.
8.5 Fault instruction and solution
Do as the following after the VFD fault:
1. Check to ensure there is nothing wrong with the kepad. If not, please contact with the local INVT
office.
2. If there is nothing wrong, please check P07 and ensure the corresponding recorded fault
parameters to confirm the real state when the current fault occurs by all parameters.
3. See the following table for detailed solution and check the corresponding abnormal state.
4. Eliminate the fault and ask for relative help.
5. Check to eliminate the fault and carry out fault reset to run the VFD.
8.5.1 VFD faults and troubleshooting resolutions
Code
Fault
Cause
Solution
OUt1
Inverter unit U
phase
protection
The acceleration is too fast
There is damage to the
internal to IGBT of the phase
Misoperation is caused by
interference.
The connection of the driving
Increase the ACC time
Change the power unit
Check the driving wires
Check if there is strong
interference to the external
equipment
OUt2
Inverter unit V
phase
protection
