6A–94 ENGINE MECHANICAL
Crankshaft
Removal
015EY00184
Legend
(1) Crank pulley
(2) Oil seal
(3) Adjusting plate
(4) Front cover
(5) Gasket
(6) Piston with connecting rod
(7) Connecting rod bearing
(8) Thrust bearings
(9) Thrust bearings
(10) Crank bearings
(11) Crankshaft
(12) Slinger
(13) Crankcase
