3 -20
Swing Reduction Gear Oil Recycling
T
o aid maintenance, the drain oil from the motor section
is used as lubricating oil for the swing gearbox,
eliminating the need to replace the oil in the gearbox.
Section E
Hydraulics
9803/6020
Section E
3 - 20
Issue 1
Schematics
289490
A
B
C
D
E
G
F
L
H
J
K
M
A
P
r
essu
r
e Line
B
Retu
r
n Line
C
Decelerating Recycling Line
D
Filter
E
Swing Motor
F
Hydraulic Oil T
ank
G
From Contr
ol T
ank
H
Oil Flow
J
T
o Control V
alve
K
From Contr
ol V
alve
L
Without Oil Seal
M
T
o Hydraulic T
ank
116
118
