jcb JS70 Service Manual

4 - 5
Emergency Stop
Section C Electrics
9803/6020
Section C
4 - 5
Issue 1
Engine Control
288360
KEY
B BLACK R RED
W WHITE Y YELLOW
Br BROWN Lg LIGHT GREEN
P PINK Sb SKY BLUE
V VIOLET L BLUE
G GREEN Gr GREY
O ORANGE
1 2 3 4
5 6 7 8
9 0
!
A
G
B
C
D
E
F
P
N
Q
J
K
L
H
M
1
Potentiometer
2
Potentiometer
3
Throttle Switch Input
4
L Mode
5
Air Con.
6
Potentiometer Input
7
Throttle Switch
8
Throttle Switch
9
Emergency Stop
0
Starter switch ACC
!
One Touch Idle
A
Left Switch Panel
B
Starter Switch
C
One Touch Idle Switch
D
Fuse Box
E
Engine Stop Relay
F
Stop Solenoid
G
Emergency Stop
H
Right Switch Panel
J
Starter Switch Input
K
Engine Stop
L
L Mode
M
Engine Stop Input
N
Throttle Motor
P
Potentiometer
Q
Motor Driver
