SC-910, SC-380, EC-10B (September, 2003) 1/5
OPERATION PANEL The operation panel can be selected according to the process.
SC-910
IP-100B, IP-100C
CP-160A
CP-160B, CP-160D
SC-910/M91
SC-910 CONTROL BOX
SC-910/M91 CONTROL BOX/COMPACT MOTOR UNIT
● SC-910 model control box is resistant to voltage fluctuations.
It comes with a compact and energy-saving type switching
power supply system that does not use a transformer. This
contributes to improved reliability.
● The M91 model compact motor unit featuring low vibration
and low noise capabilities is installed on the control box.
● The number of revolutions can be selected from among
three different types (standard, slow and fast) according to
the preference of the operator. In addition to this feature,
the control box incorporates many different functions for
upgraded workability.
● The operation panel has been provided with a large user-
friendly LCD. A pictograph and set values are shown on
the same screen, which promises improved operability of
the panel.
● The operation panel has been provided with a variety of
communication and maintenance control features and is
able to store data on a SmartMedia or personal computer.
● The features of the operation panel can be updated
without the need for changing the PWB/ROM.
● Pattern sewing can be performed by the number of stitch
control feature.
● Four different kinds of pattern sewing are possible: automatic
reverse stitching, constant-dimension sewing, rectangle-
shape sewing, and multi-layer stitching.
The maximum number of stitches that can be set for
automatic reverse stitching (single or double) is 19.
AC SERVOMOTOR/ELECTRONIC-STOP MOTOR SERIES
IP-100 CP-160
To Next Page
