DLM-5400N-7, DMN-5420N-7 (September, 2003) 1/3
DLM-5400N-7
4,500rpm
Bottom-feed
4mm (normal/reverse feed)
83kg
DMN-5420N-7
5,000rpm
(max. 4,000rpm with the stitch
length set to 4mm or more)
Needle-feed
5mm (normal feed), 3mm (reverse feed)
84kg
DLM-5400N-7
● The knife is capable of cutting any kind of material regardless of its
thickness or toughness, including heavy-weight material, elastic
material and brushing material.
● Since the knife lever has been plasted so as to prevent rust, there is
no need to worry about the material becoming soiled with rust.
● The thread trimmer is designed to cut various threads of different
thicknesses, so the range of the applicable thread thickness number
has been widened. The thread trimmer can therefore cut even a
thick thread with ease.
● The cloth trimming knife has been designed so that it can move as
much as 5.5mm toward you from the center of the needle.
DMN-5420N-7
SPECIFICATIONS
Model name
Max. sewing speed
Feed system
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle (at the time of delivery)
Hook
Max. thickness of the material to be cut
Lubrication
Lubricating oil
Automatic reverse feed function
Power requirement
Power consumption
Total weight
30.7mm
By hand : 5.5mm, By knee : 10mm
DB×1 (#14) #9〜#18, For JE: 134 (Nm90)
Automatic-lubricating full-rotary hook
4mm
Automatic
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Provided as standard
Single-phase 100〜120V, 200〜240V, 3-phase 200〜240V
650VA
OPTIONS
＊To retrofit the AE-4 to your existing machine, I/O unit A (part number: 400-06080), which is separately available, is required.
Model
AK85
AE-4
＊
ED-2
Part No.
―
GAE-040000A0
―
Feature
―
When the amount of remaining bobbin thread reaches the setting, the buzzer will sound to warn
the operator not to press on the front part of the foot pedal. With this function, the operator
doesn’t have to look away from the sewing work to check the bobbin thread.
When the sensor detects a material edge, it immediately stops the sewing machine and actuates
the thread trimmer. This enhances productivity by allowing the operator to conduct sewing
work without running to look out for missing stitches.
Description
Auto-lifter
Remaining bobbin
thread detector
Material edge sensor
DLM-5400N-7-WB/CP-160A
1-needle, Bottom-feed, Lockstitch Machine
with Vertical Edge Trimmer and Automatic Thread Trimmer
1-needle, Needle-feed, Lockstitch Machine
with Vertical Edge Trimmer and Automatic Thread Trimmer
