MO-6900S Series (September, 2003) 1/4
● Since the machine comes with a needle-thread take-up mechanism
as well as a looper thread take-up mechanism, to offer upgraded
responsiveness from light- to heavy-weight materials with a lower
applied tension, it achieves well-tensed soft-feeling seams that
flexibly correspond to the elasticity of the material at the maximum
sewing speed of 8,000 to 8,500rpm. To offer improved sewing
capabilities as well as to prevent stitching misshapes, the machine
is equipped as standard with the needle thread heat remover and
needle cooler.
SPECIFICATIONS
Super-high-speed, Overlock / Safety Stitch Machine
M
O
-6900S Series
MO-6914S
Model name MO-6904S MO-6914S MO-6916S
Stitch type 1-needle overlock 2-needle overlock Safety stitching
Stitch style in the U.S.A. 504 514 516
Max. sewing speed 8,500rpm 8,000rpm 8,000rpm
Stitch length 0.8〜4mm 1.5〜4mm
Needle gauge (mm) − 2.0, 2.4, 3.2 2.0, 3.2, 4.0, 4.8, 4.8+2.0
Overedging width (mm) 1.6, 3.2, 4.0, 4.8 3.2, 4.0, 4.8 3.2, 4.0, 4.8, 6.4
Differential feed ratio For gathering 1:2 (max. 1:4), For stretching 1:0.7 (max. 1:0.6)
Needle bar stroke 24.5mm
Inclination angle of the needle 20°
Needle bar bushing Upper/lower bushing method
Needle DC×27(excluding some subclass model)
Max. lift of the presser foot 7mm(excluding some subclass model)
Max. presser foot pressure 63.7N (6.5kg)
Stitch adjusting method By push-button
Differential-feed adjusting method By lever (with micro-adjustment)
Weight of the machine head 28kg
Lubrication Automatic
Lubricating oil JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler Provided as standard (excluding MO-6945S)
Needle thread heat remover Provided as standard (excluding MO-6945S)
Micro-lifter Provided as standard
SUBCLASS MACHINE LIST
Seams Model No.
Materials
Number
of
needles
Number
of
threads
Needle
gauge
(mm)
Overedging
width (mm)
Number
of
feed dog
rows
Stitch
length
(mm)
Presser
lifting
amount
(mm)
Needle system
Max.
sewing
speed
(rpm)
Bottom
differential-
feed ratio
Remarks
MO-6904S-0D4-300 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0E4-300 1 3 − 4.0 2 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0F4-300 1 3 − 4.8 2 4 1:0.7〜1:2 7 DC×27 #11 8,000
MO-6904S-0D6-300 1 3 − 3.2 3 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0E6-300 1 3 − 4.0 3 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0F6-300
L〜M
13− 4.8 3 4 1:0.7〜1:2 7 DC×27 #11 8,000
MO-6904S-0D4-3F0 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0E4-3F0 1 3 − 4.0 2 4 1:0.7〜1:2 7 DC×27 #11 8,500
For soft-chains
MO-6904S-0D6-3F0 1 3 − 3.2 3 4 1:0.7〜1:2 7 DC×27 #11 8,500
MO-6904S-0D4-3F6 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 8,500
■ 1-needle overlock
● For runstitching in general fabric
