DDL-5600, 5600N-7 (September, 2003) 1/2
Model name
Application
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle
(at the time of delivery)
Thread
Hook
Lubrication
Lubricating oil
DDL-5600NJ
For jeans
4,000rpm
5mm (normal/reverse feed)
DDL-5600NL
For heavy materials
36mm
By hand: 5.5mm, By knee: 13mm
DB×1 (#21) #20〜#23
For JE: 134 (Nm130)
#30〜#8, B46〜B92, Nm=60/3〜30/3
Horizontal-axis double-capacity hook
Automatic
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
8mm (normal/reverse feed)
3,000rpm
DDL-5600NR
For leather shoes
Model name
Application
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle
(at the time of delivery)
Thread
Hook
Lubrication
Lubricating oil
Automatic reverse feed
function
Power requirement
Power consumption
Total weight
DDL-5600NJ-7
For jeans
4,000rpm
5mm (normal/reverse feed)
DDL-5600NL-7
For heavy materials
36mm
By hand: 5.5mm, By knee: 13mm
DB×1 (#21) #20〜#23
For JE: 134 (Nm130)
#30〜#8, B46〜B92, Nm=60/3〜30/3
Horizontal-axis double-capacity hook
Automatic
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Provided as standard
Single-phase 100〜120V, 200〜240V, 3-phase 200〜240V
650VA
81kg
8mm, 5mm (reverse feed)
3,000rpm
DDL-5600NR-7
For leather shoes
● The machine is equipped with a link mechanism which is highly
evaluated for its straightness, consistency and durability.
Thanks to this mechanism, the machine is capable of making well-
tensed, beautifully finished seams, regardless of the type of heavy
materials. The maximum stitch length is as long as 8mm (with
the L-type machine for the sewing heavy materials with long stitch
length), thereby making the machine widely applicable to the
sewing of heavy materials, such as bags, requiring a longer stitch
length.
● Changing the bobbin is troublesome, especially when using a
thick thread. This machine, however, is equipped with a double-
capacity hook, thereby reducing the frequency of changing the
bobbin. Thanks to this feature, greater efficiency is assured.
DDL-5600N
DDL-5600N-7
(with automatic thread trimmer)
1-needle, Lockstitch Machine with Double-capacity Hook
SPECIFICATIONS
DDL-5600N-7-0B/CP-160A
