LZ-2280N, 2281N, 2282N, 2282N-7, 2284N, 2284N-7, 2286N, 2288N, 2285N, 2280NU, 2284NU, 2284NU-7 (September, 2003) 1/6
LZ-2284N-7-WB/CP-160B
● The hook driving shaft offset mechanism assures trouble-free and
consistent zigzag stitching.
● The market-proven hook and thread take-up lever enables sewing
with upgraded consistency with a lower tension applied to the thread.
● Greater durability is secured by preventing the hook from heating up
when the machine is running at high speeds.
● The highly reliable machine head is structured to reduce operating
noise and prevent oil leakage.
● The machine ensures easy adjustment of zigzag width and feed pitch.
● The adjustable range of the feed mechanisms has been widened,
thereby upgrading the machine's responsiveness to materials.
LZ-2280N SERIES
● The standard zigzag stitching machine creates softly
finished seams. The needle rocking mechanism is
provided with a triangular cam which helps produce
beautiful seams with consistency.
LZ-2280N
(standard zigzag)
● The maximum needle throw is 10mm.
The needle rocking mechanism means a higher
degree of accuracy, thereby leading to a very high
performance.
LZ-2286N
(3-step zigzag)
● The pressure of the fagoting holder can be
separately adjusted by the left- and right-hand
sections in order to prevent an uneven material
feed.
LZ-2285N
(fagoting)
● The machine is able to perform eleven different
kinds of zigzag stitching only by a quick procedure
to replace the cams.
LZ-2288N
(with changeable pattern cams)
● The machine incorporates a built-in lower knife that
trims only the lower material. This allows the
machine to simultaneously attach lace to the body
of the foundation and trim only the body during
processes to attach lace to the bottoms or tops of
slips or to the joint seam lines of shorts.
LZ-2282N
(standard zigzag/with lower knife)
LZ-2282N-7
● Two kinds of gauges can be selected in accordance with the
application of the machine: an A-type gauge with a zigzag width
of 5mm, and a B-type gauge with a zigzag width of 8mm.
The needle rocking cam is provided with a triangular cam which
helps produce beautiful seams with consistency.
LZ-2281N
(standard wider zigzag)
High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
High-speed, 1-needle, Lockstitch, Zigzag Stitching Machine
with anti-material-slip capability
● With its newly developed feed mechanism, the machine prevents
“uneven feed of the upper and lower cloths” when sewing girdles
and body suits made of slippery, elastic materials.
● Drop-feed sewing machines have been widely said to feed in the
lower cloth more quickly than the upper cloth. However, this
machine prevents uneven feed between the upper and lower cloths
in spite of its a drop-feed mechanism.
In appearances, the gauge parts are identical to those of a
conventional zigzag stitching machine, and operability is in no way
affected by the newly developed feed mechanism.
(standard zigzag/with lower knife
and automatic thread trimmer)
● The operator can easily switch the needle-throwing pattern between
the standard and 3-step zigzag stitching patterns using the lever
located in the free space under the arm.
(Time required: Approx. 15 sec)
When changing the sewing product or design, there's no need to
adjust the sewing machine head or machine layout.
LZ-2284N
LZ-2284N-7
(with standard/3-step zigzag stitching pattern changeover
function and automatic thread trimmer)
(with standard/3-step zigzag stitching
pattern changeover function)
LZ-2280NU
(standard zigzag)
LZ-2284NU
LZ-2284NU-7
(with standard/3-step zigzag stitching pattern
changeover function)
(with standard/3-step zigzag stitching pattern
changeover function and automatic thread trimmer)
