PLH-981, 982, PLN-985, 986 (September, 2003) 1/2
PLH-981
PLH-981
PLN-986
PLN-986
SPECIFICATIONS
● With JUKI's unique slide thread take-up lever, feed mechanism, and
vertical-axis hook, the machine provides well-tensed, neatly finished
seams every time.
● The stitch length can easily be adjusted with the stitch dial.
Reverse-feed stitching is actuated by a simple press of the lever.
The machine incorporates a large pulley that can be turned smoothly
by hand.
● The face plate is designed to provide a clear view of the needle entry
area and enable smooth thread feeding.
PLH-981
(1-needle)
PLH-982
(2-needle)
Post-bed, Bottom-feed Lockstitch Machine
● With a needle-feed mechanism that operates in synchronization with the
bottom-feed, the machine produces beautiful seams free from slippage
even when sewing slippery or hard-to-feed materials.
PLN-985
(1-needle)
PLN-986
(2-needle)
Post-bed, Needle-feed Lockstitch Machine
Model name
Feed system
Max. sewing speed
Max. stitch length
Needle bar stroke
Needle gauge (mm)
Lift of the presser foot
Thread take-up
Hook
Needle (at the time of delivery)
Thread
Lubrication
Lubricating oil
Post height
Bed size
Weight of the machine head
PLH-981 PLH-982 PLN-985 PLN-986
1-needle 2-needle 1-needle 2-needle
Bottom-feed Needle-feed
2,500rpm
4mm (normal/reverse feed)
36mm 33.4mm
─ 1.2, 1.6, 2.0, 2.4 (standard) ─ 2.0, 2.4 (standard)
By hand: 7mm, By knee: 10mm By hand: 6.5mm, By knee: 9mm
Slide type
Vertical-axis hook
DP×5 (#18) #16〜#21 DP×5 (#16) #16〜#21
#40〜#8, B33〜B92, Nm=90/3〜30/3
By an oiler
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
178mm 179mm
517mm×178mm
36kg 40kg
