DDL-8700, 8700-7 (September, 2003) 1/2
Model name
Application
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle
(at the time of delivery)
Feed dog
Hook
Lubrication
Lubricating oil
Weight of the machine head
DDL-8700 DDL-8700A DDL-8700H
For medium-weight materials For light-weight materials For heavy-weight materials
5,500rpm 4,000rpm
5mm 4mm 5mm
30.7mm 35mm
By hand: 5.5mm, By knee: 13mm By hand: 4mm, By knee: 9mm By hand: 5.5mm, By knee: 13mm
DB×1 (#14) #9〜#18 DA×1 (#9) #9〜#11 DB×1 (#21) #19〜#23
For JE: 134 (Nm90) For JE: 134 (Nm65) For JE: 134 (Nm130)
4-row 3-row
Automatic-lubricating full-rotary hook
Automatic
JUKI Machine Oil No.7 (equivalent to ISO VG7)
28kg
Model name
Application
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle
(at the time of delivery)
Feed dog
Hook
Lubrication
Lubricating oil
Automatic reverse feed
function
Wiper
Power requirement
Power consumption
Total weight
DDL-8700-7 DDL-8700A-7 DDL-8700H-7
For medium-weight materials For light-weight materials For heavy-weight materials
5,000rpm 4,000rpm
4mm 5mm
30.7mm 35mm
By hand: 5.5mm, By knee: 13mm By hand: 4mm, By knee: 9mm By hand: 5.5mm, By knee: 13mm
DB×1 (#14) #9〜#18 DA×1 (#9) #9〜#11 DB×1 (#21) #19〜#23
For JE: 134 (Nm90) For JE: 134 (Nm65) For JE: 134 (Nm130)
4-row 3-row
Automatic-lubricating full-rotary hook
Automatic
JUKI Machine Oil No.7 (equivalent to ISO VG7)
Provided as standard
Provided as standard for DDL-8700-7-WB model.
Single-phase 100〜120V, 200〜240V, 3-phase 200〜240V
650VA
81kg
SPECIFICATIONS
● The optimum-balance and highly rigid machine head were created
using the latest 3D-CAD design technology. Thanks to its low
vibration and low noise feature, the machine head provides the
operator with a comfortable work environment. In addition, the
distance from the machine arm to the needle on the front of the
machine head is sufficiently wide to allow easy handling of the
sewing material.
The machine inherits the desirable features, such as high-speed
stitching performance, extreme stitching performance, ease of
operation, and reliability, from the highly evaluated previous JUKI
lockstitch machines.
● The thread take-up, hook, thread path, presser foot and feed
mechanisms have been thoroughly investigated and modified to
enable low-tension sewing. The machine flexibly responds to
various kinds of materials, producing beautiful seams of consistent
quality.
● Enhanced maintainability is ensured by the improved machine head,
such as incorporation of an eccentric pin that is used to adjust the
feed dog. In addition, the machine is provided with a mounting
seat for attachment to improve workability while replacing the
attachment and increasing the durability of the machine bed surface.
● DDL-8700-7
The machine comes with a thread trimming mechanism that
performs speedy and sure thread trimming to achieve highly efficient
sewing work.
DDL-8700
DDL-8700-7
(with automatic thread trimmer)
1-needle, Lockstitch Machine
DDL-8700-7-WB/CP-160A
