LU-1520N-7, 1521N-7 (September, 2003) 1/2
● The remaining length of thread at the end of sewing is substantially
shortened to approximately 5mm. The machine cuts thread as thick as
#5 without fail.
● Even if the needle thread is clamped under the presser foot or walking
foot, the machine draws the needle thread onto the underside of the
material without fail, leaving no exposed thread on the right side.
The needle thread drawn onto the underside of the material can be
sewn under the seam.
● The end-of-sewing thread is kept in the seam allowance both at the
beginning and end of sewing and does not jut out from the material
edge. This function eliminates the need for thread snipping.
The operator is able to concentrate on sewing work without having to
perform thread snipping work, thereby dramatically increasing
productivity. The frequency of scissor use by the operator is
significantly reduced, thereby preventing accidents in which the scissors
damage the material.
1-needle, Unison-feed, Lockstitch Machine
with Vertical-axis Large Hook and Automatic Thread Trimmer
(needle thread roll-in and short tail type)
[Gauge for standard]
LU-1520N-7
[Gauge for LU-2200]
LU-1521N-7
LU-1520N-7-0BBAA/XC-E500
WHEN YOU PLACE ORDERS
LU152 N70BB
SC380 M
＊JUS: North America and Central and South America.
[PSC box/operation panel for SC] [Motor for SC]
Specification Code
Gauge for Standard 0
Gauge for LU-2200 1
PSC box Code
For General
Single-phase 220〜240V 07
Export
3-phase 200〜220V 11
For JUS(LA)
＊
Single-phase 110〜120V 37
3-phase 220〜240V 38
For CE Single-phase 220〜240V 34
Operation panel Code
Not provided 00000
Operation panel display language: English.
Instruction manual comes in
three different languages.
E500B
Operation panel display language: English.
Instruction manual comes in
five different languages.
E500C
Pneumatic auto-lifter Code
Pedal switch type
(AK124B)
B
DL device Code
Not provided Z
Provided A
Option Code
Not provided Z
AE-10 (Bobbin thread remaining
amount detecting device)
A
＊JUS: North America and Central and South America.
Motor Code
For General Single-phase
Export 3-phase
200〜240V 60
For JUS(LA)
＊
Single-phase 100〜120V 61
3-phase 200〜240V 62
For CE Single-phase 200〜240V 63
To Next Page
