MH-1410 (September, 2003) 1/2
MH-1410D/AK122/V072
SPECIFICATIONS
● With its head mechanism to ensure optimum balance and high
rigidity, the machine achieves high-speed performance of
5,000rpm with reduced operating noise and vibration.
● And now that an automatic lubricating system and strong needle-
feed mechanism are newly adopted, the machine guarantees
improved reliability and durability.
● The MH-1410 is a needle-feed machine noted for an outstanding
feed efficiency that ensures smooth stitching at the beginning of
sewing and consistent stitch pitches when sewing multi-layered
sections.
● The machine uses a right-and-left split type needle thread take-up
guide. Even when the right and left needles sew materials of
different thicknesses, separate stroke can be set for the right and
left thread take-up guide to ensure consistently excellent seam
quality.
● The differential between the needle-feed amount and bottom-feed
amount can be adjusted within the range of -5 % to +25 % of the
latter. Waving or twisting of the material can be prevented by
adjusting the differential-feed amount to suit the material
thickness, the type of folder to be used, and other sewing
conditions.
● The cloth puller is driven by a top roller, ensuring excellent feed
efficiency and uniform stitch pitches at multi-layered parts of the
material.
● The machine comes with a light-in-weight roller that offers good
adhesion on the material to ensure consistent stitch pitches
regardless of the sewing speed, i.e., both at a low high speeds.
MH-1410
High-speed, Cylinder-bed, Needle-feed, Double Chainstitch Machine
5,000rpm (when stitch length is 4.5mm or less)
4,000rpm (when stitch length is 4.5〜6.4mm)
(4,000rpm for the machine provided with cloth puller)
MH-1410A
31.8mm
(1-1/4")
Model name
Needle gauge
Number of needle
Feed system
Stitch system
Max. sewing speed
Stitch length
Stitch adjusting method
Lift of the presser foot
Needle bar stroke
Needle
(at the time of delivery)
Looper motion
Fine adjustment function
for the needle-feed amount
Peripheral dimension
of the cylinder section
Lubrication
Lubricating oil
Weight of the machine head
MH-1410B
34.9mm
(1-3/8")
MH-1410C
38.1mm
(1-1/2")
MH-1410D
6.4mm＋25.4mm＋6.4mm
(1/4"＋1"＋1/4")
Needle-feed
Needle-feed + Cloth puller (optional)
Double chainstitch
2-needle 4-needle
2.1〜6.4mm
By push-button (needle-feed/bottom-feed synchronized)
9mm
32mm
DV×57 (#21) #18〜#25
＊
Longitudinal motion method (longitudinal swing method) : Looper can be tilted for threading
Provided as standard (–5%〜 +25%)
395mm (for the machine that is not equipped with cloth puller)
Trochoidal pump type automatic lubrication
JUKI New Defrix Oil No.2 (equivalent to ISO VG32)
46kg 50kg
＊For needle size #23 to #25, a special-order gauge is required.
