MH-481, 481-5(4), 484, 484-5(4), 486-5(4) (September, 2003) 1/2
MH-481-5
● The machine comes with a thread spreading mechanism
and an adjustable needle guard to prevent stitch skipping.
The thread clamp mechanism, tension release mechanism
and needle thread draw-out mechanism enable the
machine to leave thread of a uniform length after thread
trimming, and prevent slip-off of the needle thread.
All of these mechanisms contribute to upgraded sewing.
● Safety stitching (condensation stitching) the perfect
method of preventing loose stitches, or reverse feed
stitching (back-tacking) can be alternated through the
simple adjustment of the stopper of the reverse feed lever.
Either sewing method can be used.
MH-481
MH-481-5(4)
(with automatic thread trimmer)
1-needle, Double Chainstitch Machine
● The differential-feed is the best-suited feeding device
when sewing elastic materials including double-jersey or
light-weight materials such as satin or georgette.
Beautiful, elastic seams are created, while puckering,
thread breakage and thread fraying are all prevented.
● The sewing method can be alternated between stretch
stitching and shirr stitching with the simple operation of
a lever. This lever is also used to adjust the differential-
feed ratio.
MH-484
MH-484-5(4)
(with automatic thread trimmer)
1-needle, Double Chainstitch Differential-feed Machine
● The machine comes with many different functions to prevent
uneven material feed and puckering for higher-quality seams.
The machine is adaptable to a wider variety of light-to heavy-
weight materials and takes full advantage of top-feed
mechanism. This enables unskilled operators to finish seams
of consistent quality.
● The machine comes with a forced lifting mechanism for the
top-feed dog. This enables the operator to place the material
to be sewn on the top-feed dog more smoothly. The machine
incorporates its exclusive chain-off thread presser pedal foot,
which improves seam quality and ease of operation.
MH-486-5(4)
1-needle, Double Chainstitch, Bottom and Variable Top-feed
Machine with Automatic Thread Trimmer
Model name
Feed system
Max. sewing speed
Stitch length
Top-feed amount
Differential-feed ratio
Lift of the presser foot
Needle bar stroke
Needle (at the time of the delivery)
Stitch length adjustment
Safety stitch
Looper system
Looper stroke
Looper stroke of the front and rear
Speed control
Lubrication
Lubricating oil
Power consumption
MH-481 MH-481-5(4) MH-484 MH-484-5(4) MH-486-5(4)
Bottom-feed Differential-feed Bottom and variable top-feed
5,500rpm 4,500rpm
1〜4mm
Main feed: 1〜4mm
1〜5mm
Differential-feed: 1〜5.6mm
― ― 0〜7mm
Max. gathering stitching 1: 3
― (standard 1: 1.5) ―
Max. stretch stitching 1: 0.5
By hand: 5mm, By knee: 10mm By hand: 5mm, By knee: 7mm
30mm 33mm
TV×7 (#11) #9〜#18 TV×7 (#11) #9〜#21
By dial
Condensation stitch/reverse stitching (by feed lever)
Inclined crank
21.5mm
2.1〜3.3mm 3.2mm
― ＊(1) ― ＊(1) ＊(1)
Automatic
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
― ＊(2) ― ＊(2) ＊(2)
＊(1) From 500rpm to the Max. sewing speed determined by the pulley used (externally adjustable)
＊(2) Single-phase,3-phase (400W)
SPECIFICATIONS
Men's shirts Attaching yokes on the back
Slacks, pantaloons, ski pants Attaching waist belts, joining sides, seam insides, or hip seams.
Coats, blazers Sewing the center of the back, joining sides, sewing sleeves, belts, collars, and sewing the facing on to the front.
Skirts Sewing the center and joining sides
One-piece suits, blouses, negligees Making pleats or gathers
Uniforms, jumpers Sew side and sew interlining on the wrong side of the material
Interior decorations Making pleats or gathers
APPLICATION FOR MH-481/MH-484/MH-486 SERIES
