MO-6700S Series (September, 2003) 1/4
● Since the machine comes with a needle-thread take-up mechanism
as well as a looper thread take-up mechanism, to offer upgraded
responsiveness from light- to heavy-weight materials with a lower
applied tension, it achieves well-tensed soft-feeling seams that
flexibly correspond to the elasticity of the material at the
maximum sewing speed of 7,000rpm.
● The machine incorporates various mechanisms as standard, such
as a differential-feed micro-adjustment mechanism and an external
adjustment mechanism for adjusting the feed dog inclination as
well as increasing the differential feed ratio, which can be easily
adjusted to finish seams that perfectly match the material to be
used.
SPECIFICATIONS
SUBCLASS MACHINE LIST
High-speed, overlock /safety stitch machine
M
O
-6700S Series
MO-6714S
Model name MO-6704S MO-6714S MO-6716S
Stitch type 1-needle overlock 2-needle overlock Safety stitching
Stitch style in the U.S.A. 504 514 516
Max. sewing speed 7,000rpm
Stitch length 0.8〜4mm 1.5〜4mm
Needle gauge (mm) − 2.0, 2.4, 3.2 2.0, 3.2, 4.0, 4.8, 4.8+2.0
Overedging width (mm) 1.6, 3.2, 4.0, 4.8 3.2, 4.0, 4.8 3.2, 4.0, 4.8, 6.4
Differential feed ratio For gathering 1:2 (max. 1:4), For stretching 1:0.7 (max. 1:0.6)
Needle bar stroke 24.5mm
Inclination angle of the needle 20°
Needle mechanism Needle bar method and upper/lower bushing
Needle DC×27 (excluding some subclass model)
Max. lift of the presser foot 7mm (excluding some subclass model)
Max. presser foot pressure 63.7N (6.5kg)
Stitch adjusting method By push-button
Differential-feed adjusting method By lever (with micro-adjustment)
Weight of the machine head 28kg
Lubrication Automatic
Lubricating oil JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler Option
Needle thread heat remover Option
Micro-lifter Provided as standard
Seams Model No.
Materials
Number
of
needles
Number
of
threads
Needle
gauge
(mm)
Overedging
width (mm)
Number
of
feed dog
rows
Stitch
length
(mm)
Presser
lifting
amount
(mm)
Needle system
Max.
sewing
speed
(rpm)
Bottom
differential-
feed ratio
Remarks
MO-6704S-0D4-300 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0E4-300 1 3 − 4.0 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0F4-300 1 3 − 4.8 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0D6-300 1 3 − 3.2 3 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0F6-300 L〜M1 3− 4.8 3 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0D4-3F0 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0E4-3F0 1 3 − 4.0 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
For soft-chains
MO-6704S-0D6-3F0 1 3 − 3.2 3 4 1:0.7〜1:2 7 DC×27 #11 7,000
MO-6704S-0D4-3F6 1 3 − 3.2 2 4 1:0.7〜1:2 7 DC×27 #11 7,000
■ 1-needle overlock
● For runstitching in general fabric
