8-Port Gigabit Ethernet SFP XPIM Basic Configuration

The 8-Port Gigabit Ethernet small form-factor pluggable Gigabit-Backplane Physical

Interface Module (SFP XPIM) provides connectivity to a single Gigabit Ethernet device

or to a network. After you install the XPIM in the services gateway, you configure a network

interface on the XPIM.

NOTE: The SRX550 High Memory Services Gateway does not support

hot-swappable functionality for GPIMs.

To configure a network interface on the 8-Port Gigabit Ethernet SFP XPIM :

1. Verify that the 8-Port Gigabit Ethernet SFP XPIM is installed in the services gateway:

user@host >show chassis hardware

Hardware inventory:

Item Version Part number Serial number Description

Chassis DA3515AK0016 SRX550M

Midplane REV 03 750-063950 ACMW7426

Routing Engine REV 03 711-062269 ACMT8374 RE-SRX550M

FPC 0 FPC

PIC 0 6x GE, 4x GE SFP Base

PIC

Xcvr 6 REV 02 740-011613 PLN4Q4R SFP-SX

Xcvr 7 REV 02 740-011613 PLH5R83 SFP-SX

Xcvr 8 REV 02 740-011613 PPF68ZA SFP-SX

Xcvr 9 REV 02 740-011613 AM1301SZEZL SFP-SX

FPC 1 REV 00 750-064611 ACMX2090 FPC

PIC 0 1x T1E1 mPIM (RoHS)

FPC 2 REV 00 750-064613 ACMW2386 FPC

PIC 0 1x Serial mPIM (RoHS)

FPC 3 REV 00 750-064614 ACMZ1330 FPC

PIC 0 16x GE POE gPIM (RoHS)

FPC 6 REV 02 750-064615 ACMS8119 FPC

PIC 0 8x SFP gPIM (RoHS)

Xcvr 0 REV 01 740-013111 92244027 SFP-T

Xcvr 1 REV 02 740-011613 PLH5KLM SFP-SX

Xcvr 2 REV 02 740-011613 PPF68YU SFP-SX

Xcvr 3 REV 02 740-011613 PN356ST SFP-SX

Xcvr 4 REV 02 740-011613 PLN54T1 SFP-SX

Xcvr 5 REV 01 740-020465 DDK2008229 SFP-1000BASE-BX10-D

Xcvr 6 REV 02 740-011613 PPF68YV SFP-SX

Xcvr 7 REV 02 740-011613 PPF68YW SFP-SX

Power Supply 0 Rev 04 740-028131 WG02251 PS 645W DC

Power Supply 1 Rev 04 740-028131 WH02925 PS 645W DC

2. Verify that the PIC on the XPIM is online:

user@host> show chassis fpc pic-status

3. Verify that the network interface that you want to configure on the XPIM is up:

SRX300 Series and SRX550 High Memory Gateway Interface Modules Reference

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
