Juniper SRX320 User Manual

CHAPTER 8
T1/E1 Mini-Physical Interface Module
•
RJ-48 Connector to RJ-48 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R) on page 47
•
RJ-48 Connector to DB-15 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R) on page 48
RJ-48 Connector to RJ-48 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface
Module (SRX-MP-1T1E1-R)
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) uses an RJ-48 cable, which
is not supplied with the Mini-PIM.
CAUTION: To maintain agency approvals, use only a properly constructed,
shielded cable.
Table 35 on page 47 lists the RJ-48 connector to RJ-48 connector (straight) pinouts.
Table 35: RJ-48 Connector to RJ-48 Connector (Straight) Pinouts
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on 1-Port
T1/E1 Mini-PIM)
RX, Ring, –11
RX, Tip, +22
TX, Ring, –44
TX, Tip, +55
Shield/Return/Ground33
Shield/Return/Ground66
No connectNo connect7
No connectNo connect8
47Copyright © 2017, Juniper Networks, Inc.

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
