Juniper SRX320 User Manual

V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 47 on page 63 gives the V.35 DCE cable pinouts.
Table 47: V.35 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Frame Ground-A15
Signal Ground-B57
Request to Send-C37
Clear to Send-D48
Data Set Ready-E33
Received Line Signal Detector-F13
Data Terminal Ready-H9
Test Mode-K45
Transmit Data (A)2P1
Receive Data (A)59R60
Transmit Data (B)1S2
Receive Data (B)60T59
Terminal Timing (A)6U5
Receive Timing (A)51V52
Terminal Timing (B)5W6
Receive Timing (B)52X51
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
--26 to 25
63Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
