Juniper SRX320 User Manual

Table 48: V.35 DTE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Receive Timing (B)5X6
Transmit Timing (A)55Y56
Transmit Timing (B)56AA55
---22 to 21
---26 to 25
---18 to 17
Related
Documentation
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 56
•
• RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 58
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 66
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 49 on page 65 gives the X.21 DCE cable pinouts.
Table 49: X.21 DCE Cable Pinouts for the 1-Port Serial Mini-PIM
DescriptionLFH-60 PairingDB-15 PinLFH-60 Pin
Shield Ground-115
Transmit Data (A)221
Control (A)38337
Receive (A)59460
Indicate (A)47548
Signal Element Timing (A)51652
Signal Ground-857
Transmit Data (B)192
65Copyright © 2017, Juniper Networks, Inc.
Chapter 10: Serial Mini-Physical Interface Module Cable Specifications

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
